Overhead Materials Handling Light Crane Systems

CEARS Gantry System is a proven system and efficient solution for variety of overhead material

handling requirement for auto and engineering industry. CEARS Gantry System is used for handling and

assembling of heavy material in three dimensional work space. The operator does not feel fatigue in

handling heavy material which results in enhancement of production to great extent.

CEARS sections are cold rolled Special Track Sections in steel with a smooth surface finish. The dead

weight being very low and with extremely smooth running trolleys the crosstracker allows heavy and

odd size goods to be moved quickly and effortlessly. Special guide surfaces and slightly inclined contact

surfaces gurantee smooth trolley travel.

All rails are powder coated from inside as well as outside.

Cears rails are available in four different sizes -

CGS-1G, CGS-1, CGS-2L and CGS-2.

CEARS GANTRY SYSTEMS

Turn-key installation of CEARS Gantry System, IT Guns, Non-IT Guns, Transformers and Controllers

Single Girder Crane Double Girder Crane Monorails Track Changers

Turntables Friction Wheel Drives Monorails with Internal Bus Bars

Curved Runways Hoists

NA S H r es er v e s t he r igh t t o c h ange s p ec if ic at ion s an d appe ar an ce w ith out pr ior not ic e .

ISO 9001

NASH Robotics and Automation Pvt. Ltd.

93/9, MIDC, Satpur, Nashik 422 007, India

Phones : +91 - 253 - 2353382, 2352180, 2350680

Fax : +91 - 253 - 2351780

Email : co@nashrobotics.com

Web : www.nashrobotics.com

IS O 90 01/EN I SO 9001

A PPR O VE D B Y IR Q S

Installation of Cears Gantry System including Hoists for entire Body Shop at Maruti Suzuki, Manesar.

All Hoist Rails & Track changers supplied with Internal Bus bars.

Track Changers

Pneumatic, Motorised or Manual

Friction Wheel Drives

Friction Wheel Drive Assembly

consists of gear box with a

large friction wheel mounted

with dished washers which

provides constant pressure

between the surface track and

driving wheel. Friction wheel

drive assembly is connected

to a hoist load trolley with a

load bar.

Hoist and drive assembly can

be operated from single

pendent.
